Reliable I/O-based Obstacle Avoidance Performance
USB Rapid Zone Setup
Cost-Optimized Design and Operation
| Measuring range | 0.1-25m Ranging capability: 0.15-6m@3% reflectivity 0.1-8m@10% reflectivity 0.1-25m@90% reflectivity 0.1-25m@ PL560 reflectivity |
|---|---|
| Blind zone range (measured from optics cover) | 7.5cm |
| Range accuracy | ±30mm |
| Statistical error(1σ) | ±7mm@10m, 10% reflectivity |
| Angular resolution | 0.33°@25Hz |
| Scanning method | dToF |
| Scanning angle | 270° |
| Light source | Pulsed laser diode |
| Laser wavelength | 905nm |
| Laser safety class | Class 1 |
| Beam divergence angle | 10mrad |
| Output resolution | 1.0 mm |
| Sampling rate | ≤27kHz |
| Response time | ≤40ms(25Hz) ≤66ms(15Hz) |
|---|---|
| Supply voltage | DC12~26V |
| Power consumption | ≤9W |
| Interface | Ethernet(TCP) |
| Field sets | 16×3 |
| Input | 4 PNP&NPN |
| Output | 3 PNP&NPN |
| Dimension(W×H×D) | 50mm × 76mm × 50mm |
|---|---|
| Weight | 0.13kg |
