外形尺寸

技术参数

扫描系统

Detection distance Output range: 25m Detection capability: ≥ 25m@90 %Reflectivity ≥ 10m@10 %Reflectivity
Scanning principle dToF
Scan angle 270°
Angular resolution (customizable) 0.33°@15Hz/0.33°@25Hz
Scanning precision ±20mm
Types of optics Pulse laser diode
Wavelength 905nm
Laser level 1
Beam divergence angle (full angle) 10mard
Output Resolution 1.0mm
Sampling rate (customizable) ≤28KHz
Vibration resistance 10~55Hz, dual amplitude 1.5mm, scanning rate

系统整机

Response time ≤66ms(15Hz)
Operation temperature -10℃~50℃
Storage temperature -30℃~70℃
Power supply voltage DC12-26V
Power consumption ≤3W
Output type Ethernet(TCP/IP)

机械参数

Dimensions (width x height x depth) 50mm×50mm×77mm（max）
Weight (bare metal weight) Approximately 0.13kg
Shell Material Aluminum alloy
Shell color white

环境参数

Shell protection level IP65 GB/T 4208-2017
Ambient light immunity ≥40000Lux
Impact resistance Half sine wave impact, 15g, 11ms, 3 times/impact surface, a total of 18 impacts GB/T 2423.5-2019
Electrostatic Discharge Level 3 (contact discharge ± 6kV, air discharge ± 8kV) GB/T 17626.2-2018
Pulse group Level 2 (1kV) GB/T 17626.4-2018
Radiated disturbance test A-grade industrial grade GB/T 9254-2008
Conducted disturbance test A-grade industrial grade GB/T 9254-2008
PFMF immunity Level 5 (100A/m) GB/T 17626.8-2006
Constant damp heat test Temperature 50 ℃, humidity 95%, 72H GB/T 2423.3-2012

产品应用方向

AGV

robot

robot
